1024 DMX channels, DMX512/1990 standard, Output port with optical isolated.
Up to 180 intelligent Fixtures or 180 Dimmer may be connected.
Up to 42 channels each Fixture. Fixture Library mode, “pearl”  Library compatible.
400 Playback program, 200 Group, 210 Preset, 100 Snapshot.
Shape track control is provided to control such effects as circles, lines and dimmer effect, etc.
Chase trigger mode selectable: Auto1, Auto2, Music synchronously and MIDI.
USB port is provided. USB-disk can record the data of controller, Controller can be upgraded through the USB port.
1 VGA port, user can connect it to the colorful CRT or LCD displays (OPTIONAL).
LCD display with backlight.
12V accessory operate light (OPTIONAL).
Power supply: AC 110-240V / 50-60Hz
Size: 500×525×150mm
Weight:14Kg

Size: 500×525×150mm
Weight:14Kg
