DMX512/1990 standard, 512 DMX channels, output with optical isolated.
Up to 62 intelligent Fixtures may be connected with a maximum of 36 channels each.
Uses can allocate DMX channel to each intelligent Fixture dynamically.
16-bit X/Y control for absolutely precise movement.
Up to 80 SHAPE generators. SHAPE track control is provided to control such effects as circles, lines and shapes like 8, etc.
62 Chases, up to 100 Steps each. Trigger mode selectable: Music synchronously, Auto, Manual speed
6 Chases, 62 Scenes operated at the same time. At most 62 intelligent Fixtures can be selected simultaneously.
31 MACRO, running combination of different manual, scene and chase can be recorded to the MACRO.
USB port is provided. each USB flask-disk can record the whole data of controller,
LCD display with backlight.
Power supply: AC 90-250V / 50-60Hz
Size: 483mm x 400mm x105mm
Weight:11Kg

Power supply: AC 90-250V / 50-60Hz
Size: 483mm x 400mm x105mm
Weight:11Kg
