1. Transmitting/receiving standard DMX512 protocol data of console，and the master-slaver on line signal of the same kind of lighting each other.
2. Single key to operate，tricolor LED indicator.
    The LED indicator bright：No DMX or wireless signal.
    Red LED flash：Transmitting.
    Green LED flash：Receiving
3. 126 frequencies band, FH design, and frequency-hopping synchronization automatically.
4. 7 groups ID code to set these different wireless nets without any interfere each other in the same place.
5. Input voltage：12VDC 500mA min.
6. Communication distance：500m（visible distance）
7. Max transmitting power：20dBm
8. Receiver sensitive：-94dBm
9. Signal socket：3/5pin male XLR.
